Mini PC Q30600GER S23 Series

Name: Mini PC Q30600GER S23 Series
Brand: Qotom
SKU: Q30600GER-S23
Availability: InStock

Model: Q30600GER-S23

Total LAN8

LAN Speed1G RJ45

Serial Ports1

Key Specs

CPU: Skylake / Kaby Lake / Kaby Lake-R
Memory: DDR4 SO-DIMM · Max 32GB
LAN: 8
Storage: mSATA, SATA

Compatible Motherboard

MB4U86R-0600

This product is available via inquiry and OEM/ODM customization.

Send Inquiry

Main Features

Intel 6 th Skylake-U Processor
Intel 7 th Kabylake-U Processor
Intel 8 th Kabylake-R-U Processor
1 × Display Port, 1 × HDMI
4 × USB 3.0
1 × mSATA, 1 × Mini PCIe, 1 × M.2, 1 × SATA 3.0
1 × RS-232 (RJ-45)
8 × Realtek Gigabit LAN

Related Products

Mini PC Q30600PV S02 Series

Q30600PV-S02

Mini PC Q30400GE S20 Series

Q30400GE-S20

Mini PC Q30400GEX S10 Series

Q30400GEX-S10

Mini PC Q10800G5 S08 Series

Q10800G5-S08

Mini PC Q10900H6 S23 Series

Q10900H6-S23

Mini PC Q30400GE S10 Series

Q30400GE-S10

CPU	• Intel 6 th Skylake-U Processor • Intel 7 th Kabylake-U Processor • Intel 8 th Kabylake-R-U Processor
CPU TDP	By CPU
Memory	1 × DDR4 SO-DIMM Socket (Up to 32G, 2133/2400MHz)
Chipset	By CPU
Graphics	By CPU
LAN Chipset	8 × Realtek Gigabit LAN
Watch Dog	Yes

Power Button	1 × Power Button, 1 × Reset Button
LED	1 × Power LED,1 × HDD LED
USB	4 × USB 3.0
Serial Port	1 × RS-232 Port (RJ-45)
Power	1 × DC Jack
Video Output	1 × HDMI,1 × Display Port

Type	1 × 2.5-inch HDD/SSD
Type	1 × Mini PCIe for mSATA SSD

Mini PCIe	1 × Mini PCIe (Only Support USB Device) Full-length for 4G Half-length for Wi-Fi
M.2	1 × M.2 for Wi-Fi (E key, Type: 2230)
SIM Card Slot	1
AutoStart Jumper	Yes,1 × 3Pin, Pitch 2.54mm
DC-IN	No
CMOS Clear Jumper	Yes,1 × 3Pin, Pitch 2.0mm
GPIO	1,2 × 5Pin, Pitch 2.0mm
RS-485	0

Power Adapter	12V4A
DC Jack	5.5mm, 2.5mm

Mini PC Series

Motherboard Series

NAS Storage Series

OPS Series

Panel PC Series

Accessories

Mini PC Q30600GER S23 Series

Key Specs

Compatible Motherboard

Main Features

Processor System

Front I/O

Rear I/O

Storage

Expansion

Power

Environmental

Mechanical

OS Support

Package Contents

Order & Specification Selection

Driver Downloads

Related Products

Operating Temp	0°C~50°C
Non-Operating Temp	-20°C~80°C
Humidity	10%~90%

Material	Aluminium Alloy
Dimension	196 × 122 × 47mm
Weight	1.27kg
Mounting	VESA Mounting Bracket
Packaging Dimension	285 × 260 × 93mm
Kensington Lock	No
Cooling Mode	Fanless Design, Fan-assisted Cooling

Ordering Code	Code Name	Processor Type	Processor Number	Cores / Threads	Frequency	Cache	Graphics	TDP
Q30611GER-S23	Skylake	Celeron	3855U	2 / 2	1.6GHz	2M	Intel HD 510	15W
Q30612GER-S23	Skylake	Celeron	3955U	2 / 2	2.0GHz	2M	Intel HD 510	15W
Q30631GER-S23	Skylake	Core i3	6100U	2 / 4	2.3GHz	3M	Intel HD 520	15W
Q30651GER-S23	Skylake	Core i5	6200U	2 / 4	2.3GHz ~ 2.8GHz	3M	Intel HD 520	15W
Q30671GER-S23	Skylake	Core i7	6500U	2 / 4	2.5GHz ~ 3.1GHz	4M	Intel HD 520	15W
Q30711GER-S23	Kaby Lake	Celeron	3865U	2 / 2	1.8GHz	2M	Intel HD 610	15W
Q30712GER-S23	Kaby Lake	Celeron	3965U	2 / 2	2.2GHz	2M	Intel HD 610	15W
Q30731GER-S23	Kaby Lake	Core i3	7100U	2 / 4	2.4GHz	3M	Intel HD 620	15W
Q30751GER-S23	Kaby Lake	Core i5	7200U	2 / 4	2.5GHz ~ 3.1GHz	3M	Intel HD 620	15W
Q30771GER-S23	Kaby Lake	Core i7	7500U	2 / 4	2.7GHz ~ 3.5GHz	4M	Intel HD 620	15W
Q30811GER-S23	Kaby Lake R	Celeron	3867U	2 / 2	1.8GHz	2M	Intel HD 610	15W
Q30821GER-S23	Kaby Lake R	Pentium	4417U	2 / 2	2.3GHz	2M	Intel HD 610	15W
Q30831GER-S23	Kaby Lake R	Core i3	8130U	2 / 4	2.0GHz ~ 3.40GHz	4M	Intel UHD 620	15W
Q30851GER-S23	Kaby Lake R	Core i5	8250U	4 / 8	1.6GHz ~ 3.4GHz	6M	Intel UHD 620	15W
Q30871GER-S23	Kaby Lake R	Core i7	8550U	4 / 8	1.8GHz ~ 4.0GHz	8M	Intel UHD 620	15W
