Mini PC Q30900G6 S08 Series

Name: Mini PC Q30900G6 S08 Series
Brand: Qotom
SKU: Q30900G6-S08
Availability: InStock

Model: Q30900G6-S08

Total LAN6

LAN Speed2.5G RJ45

Serial Ports1

Key Specs

CPU: Whiskey Lake / Coffee Lake / Comet lake
Memory: DDR4 SO-DIMM · Max 32GB
LAN: 6
Storage: mSATA, SATA

Compatible Motherboard

MB2U61A-0900

This product is available via inquiry and OEM/ODM customization.

Send Inquiry

Main Features

Intel 8 th Whiskey Lake-U Processor
Intel 8 th Coffee Lake-U Processor
Intel 10 th Comet lake-U Processor
1 × Display Port, 1 × HDMI
4 × USB 3.0
1 × M.2, 1 × Mini PCIe, 1 × SATA 3.0
1 × RS-232 (RJ-45)
6 × Intel I225-V/I226-V 2.5G LAN

Related Products

Mini PC Q30400GE S20 Series

Q30400GE-S20

Mini PC Q30400GEX S10 Series

Q30400GEX-S10

Mini PC Q10800G5 S08 Series

Q10800G5-S08

Mini PC Q10900H6 S23 Series

Q10900H6-S23

NAS Q30900DS S14 Series

Q30900DS-S14

Mini PC Q30400GE S10 Series

Q30400GE-S10

CPU	• Intel 8 th Whiskey Lake-U Processor • Intel 8 th Coffee Lake-U Processor • Intel 10 th Comet lake-U Processor
CPU TDP	By CPU
Memory	1 × DDR 4 SO-DIMM Socket (Up to 32 G,21 33/24 00MHz)
Chipset	By CPU
Graphics	By CPU
LAN Chipset	6 × Intel I225-V/I226-V 2.5G LAN
Watch Dog	Yes

Power Button	1
LED	1 × Power LED,1 × HDD LED
USB	4 × USB 3.0
Serial Port	1 × RS-232 Port (RJ-45)
Reset Button	1
Video Output	1 × HDMI,1 × Display Port

Type	1 × 2.5-inch HDD/SSD
Type	1 × Mini PCIe for mSATA SSD

Mini PCIe	1 × Mini PCIe,Full-length for mSATA/4G
M.2	1 × M.2 for Wi-Fi (E key, Type: 2230)
SIM Card Slot	1
AutoStart Jumper	1, 1 × 3Pin, Pitch 2.54mm
CMOS Clear Jumper	1, 1 × 3Pin, Pitch 2.0mm
GPIO	0

Power Adapter	12V3A
DC Jack	5.5mm, 2.5mm

Mini PC Series

Motherboard Series

NAS Storage Series

OPS Series

Panel PC Series

Accessories

Mini PC Q30900G6 S08 Series

Key Specs

Compatible Motherboard

Main Features

Processor System

Front I/O

Rear I/O

Storage

Expansion

Power

Environmental

Mechanical

OS Support

Package Contents

Order & Specification Selection

Driver Downloads

Related Products

Operating Temp	0°C~50°C
Non-Operating Temp	-20°C~80°C
Humidity	10%~90%

Material	Aluminium Alloy
Dimension	155 × 127 × 48mm
Weight	0.88kg
Mounting	VESA Mounting Bracket
Packaging Dimension	261 × 218 × 75mm
Kensington Lock	No
Cooling Mode	Fanless Design

Ordering Code	Code Name	Processor Type	Processor Number	Cores / Threads	Frequency	Cache	Graphics	TDP
Q30912G6-S08	Whiskey Lake	Celeron	4305U	2 / 2	2.2GHz	2M	Intel UHD Graphics	15W
Q30921G6-S08	Whiskey Lake	Pentium	5405U	2 / 4	2.3GHz	2M	Intel UHD Graphics	15W
Q30931G6-S08	Whiskey Lake	Core i3	8145U	2 / 4	2.1GHz ~ 3.9GHz	4M	Intel UHD Graphics	15W
Q30951G6-S08	Whiskey Lake	Core i5	8265U	4 / 8	1.6GHz ~ 3.9GHz	6M	Intel UHD Graphics	15W
Q30971G6-S08	Whiskey Lake	Core i7	8565U	4 / 8	1.8GHz ~ 4.6GHz	8M	Intel UHD Graphics	15W
Q30952G6-S08	Coffee Lake	Core i5	8260U	4 / 8	1.6GHz ~ 3.9GHz	6M	Intel UHD Graphics 620	15W
Q31011G6-S08	Comet Lake	Celeron	5205U	2 / 2	1.9GHz	2M	Intel UHD Graphics	15W
Q31012G6-S08	Comet Lake	Celeron	5305U	2 / 2	2.3GHz	2M	Intel UHD Graphics	15W
Q31021G6-S08	Comet Lake	Pentium	6405U	2 / 4	2.4GHz	2M	Intel UHD Graphics	15W
Q31031G6-S08	Comet Lake	Core i3	10110U	2 / 4	2.1GHz ~ 4.1GHz	4M	Intel UHD Graphics	15W
Q31051G6-S08	Comet Lake	Core i5	10210U	4 / 8	1.6GHz ~ 4.2GHz	6M	Intel UHD Graphics	15W
Q31071G6-S08	Comet Lake	Core i7	10610U	4 / 8	1.8GHz ~ 4.9GHz	8M	Intel UHD Graphics	15W
Q31072G6-S08	Comet Lake	Core i7	10810U	6 / 12	1.1GHz ~ 4.9GHz	12M	Intel UHD Graphics	15W
Q31073G6-S08	Comet Lake	Core i7	10710U	6 / 12	1.1GHz ~ 4.7GHz	12M	Intel UHD Graphics	15W
Q31074G6-S08	Comet Lake	Core i7	10510U	4 / 8	1.8GHz ~ 4.9GHz	8M	Intel UHD Graphics	15W
